BRAND | Leser |
Product | 5262.6682 |
Internal code | PMX4927104 |
Technical specification | API Series Safety Valve, Type 526, Port R, closed cap, H2 standard cap, for steam, gas and liquids PDO: Connections: Body - Material: 54.00 bar eff/50.00 °C NPS 6 X NPS 10 1.0619/WCB/WCCPDO: 54.00 Pressure unit bar eff CDTP [bar-g] 54.00 CDTP [psi-g] 783.20 Service temperature: 50 Temperature - unit: °C - Celsius Fluid: Gas DN input: NPS 6 Inlet flange pressure class: 600# ASME B16.5 Inlet flange face: Serr spiral finish, Ra=3.2-6.3 DN output: NPS 10 Flange outlet pressure class: 150# ASME B16.5 Output flange face: Serr spiral finish, Ra=3.2-6.3 Actual hole diameter [mm] 126.0 Body - Material: 1.0619/WCB/WCC Cap material: 1.0619/WCB/WCC Spring material: Standard material Gasket material: Graphite/1.4401 H2 lift device with lock (Test Gag) Bellows: Inconel 625/ Conn.parts 316L Hat: With anti-intrusion filter Paint: Special valve paint Paint: High Temp Paint System WCB |
Discover the superior quality and performance of the Leser 5262.6682 with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 5262.6682 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 5262.6682 :
At "Parmex Automatización" SRL , we offer the 5262.6682 at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose "Parmex Automatización" SRL ?
Get Your Quote Today! Ready to enhance your operations with the 5262.6682 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leser products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
