| BRAND | Carlo Gavazzi |
| Product | CTD8V3005AXXX |
| Description | AC Solid-core Current Transformer |
| Internal code | PMX241974 |
| Weight | 0.7 |
| Technical specification | AC Solid-core Current Transformer Type CTD-8V / CTD-8H (max 30x80 mm) • Bus-bar type solid- core current transformer • Class 0.5 accuracy • Currents from 150 A to 2500 A • Up to 10 Bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-8V1500 5AXXX Solid-core current transformer with bus-bar mountng facility. Rated primary currents from 150 A to 2500 A. Model Primary current Secondary current Option Type Selection Model CTD-8V:vertical mounting CTD-8H:horizontal mounting Primary current From 150A to 2500A (Refer to the Range Table) Secondary current 1A (on request) 5A Option XXX:none XTX: tropicalization InputSpecifications Operating frequency48 to 62 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-timethermal current Ith is anyway limited by the cable/bus-bar size Extended current rating Refer to the Range Table Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications Standards According to EN60044-1 HousingABS, self-extinguishing: UL 94 V-0 MountingBus-bar mounting Standard accessoriesTwo terminal block screws. Ten bus-bar fixing screws. Ten plastic caps for bus-bar fixing screws. Two sealable terminal block covers. Special features1 A secondary current, Tropicalization Working temperature-25°C to: refer to the Range Table (-13°F to: refer to the Range Table) (R.H. < 90% non condensing @ 40°C) Storage temperature-30°C to +70°C (-22°F to 158°F) (R.H. < 90% non condensing @ 40°C) Approvals CE. cURus and CSA (150A to 1000A) Connection Screw type Cable cross section areaFrom 1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal block screws: From 1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixing screws: 0,3 Nm Protection degree IP00 (without sealable terminal covers) IP20 (with sealable terminal block covers + wire terminals) Bus-bar size Max. 30x80 mm WeightFrom 450 to 700 g |
Discover the superior quality and performance of the Carlo Gavazzi CTD8V3005AXXX with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CTD8V3005AXXX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CTD8V3005AXXX :
At "Parmex Automatización" SRL , we offer the CTD8V3005AXXX at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose "Parmex Automatización" SRL ?
Get Your Quote Today! Ready to enhance your operations with the CTD8V3005AXXX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy CTD8V3005AXXX by Carlo Gavazzi in Mexico?
You can purchase CTD8V3005AXXX by Carlo Gavazzi from "Parmex Automatización" SRL. We serve customers across Mexico, offering competitive prices and reliable service.
What is the price of the CTD8V3005AXXX?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Carlo Gavazzi in Mexico?
While we are not the official distributor or seller of Carlo Gavazzi in Mexico, we source our products from reliable channels and offer you original Carlo Gavazzi equipment at competitive prices.
How can I access CTD8V3005AXXX catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CTD8V3005AXXX on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CTD8V3005AXXX?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
