S225725 - Ziehl Mexico Sales

BRAND	Ziehl
Product	S225725
Description	Current Transformer
Internal code	PMX242542
Weight	0.12
Technical specification	STWA3D20 STWA3D, Messwandler für RCM1000V, Innendurchmesser 20 mm Rated current Kn primary/secondary 10 A / 0,0167 A Rated power 50 mVA (180 Ohm) Frequency range 42 Hz … 3 kHz Rated ambient temperature range -5 °C … +70 °C Temperature storage -25 °C … + 70 °C Rated short-time thermal current Ith 2,4 kA / 1 s Rated continuous residual current 40 A Nominal current Idyn 6 kA / 40 ms Nominal voltage 0,8 kV Rated impulse voltage 8 kV Contamination level III Dimensions STWA3D20 STWA3D35 STWA3D70 STWA3D125 Inside diameter 20 mm 35 mm 70 mm 125 mm X * Y * Z (mm) 53 * 49 * 87 68 * 49 * 103 103 * 49 * 137 173 * 63 * 200 Weight 120 g 160 g 290 g 910 g

Please Contact Us to Order to offer competitive prices and delivery time for Ziehl - S225725 Current Transformer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Mexico Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
