EK502USFLR4P070 - Stober Mexico Sales

BRAND	Stober
Product	EK502USFLR4P070
Description	synchronous servo motor
Internal code	PMX3432283
Weight	8.9
Custom code	85015220
Technical specification	MV0000101885 (>0.75... 7.50kW) Standstill current 7.70 A Rated current 5.00 A Standstill torque 6.53 Nm Engine torque 4.20 Nm Motor speed 6,000 rpm Motor power 2.64 kW ED/EK engine type description EK502USFLR4P070 Cooling type Convection cooling IC Output side IEC □ 115 PR 110 LK 130 Shaft version Ø19x40 without spring Drive controller manufacturer Ferrocontrol BG encoder connectors/type external drive controller con.23 DC link voltage 540V DC link voltage Drive controller type/ Ferrocontrol Darc-S (Elumatec) connection Connection diagram 442082 Encoder type resolver Encoder type Resolver 2-p. GR21 standard Rated speed nN 6000 rpm 540V (KEM=70) ED Plug type angle rotatable Matching plug Without mating plug Power connection connector 8-pin con.23 Position of connectors 270° Cable entry links * PTC thermal winding protection in the power connection Ambient temperature -15 to +40°C standard Thermal class (VDE 0530) 155 F Protection class (EN 60529) IP56 (EN 60529) UR version/CSA Recognized Components option 8Nm MBS/7nm MBD/PM 24VDC brake S1 Operating Servomotors operating mode K painting/1-coat painting Colour RAL 9005 deep black Painting options Output not painted Documentation language German Documentation language English

Please Contact Us to Order to offer competitive prices and delivery time for Stober - EK502USFLR4P070 synchronous servo motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Mexico Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
