BRAND | Valco |
Product | FCM2-5.15.GO.11P /00.0001.0644.1 |
Description | Fixed-calibration flow switch |
Internal code | PMX4790369 |
Technical specification | Fixed-calibration flow switch Mod. FCM2-5.15.GO.11P <horizontal or vertical mounting with flow from bottom to up> Brass body 1/2" Gas-M process connections Piston sensitive element Max working pressure 250 bar Max working temperature 90°C Fixed calibration, see available calibrations as per the technical bulletin Maximum recommended flow rate 25 l/min H2O Pressure drop at the maximum recommended flow rate 0.5 bar Replaceable and interchangeable electric head - without removing the flow switch From the pipeline Contact Reed NA Maximum electrical loads: 300VCA-dc/70VA/50W/0.5A Electrical output: Faston 6.3 mm Replaceable and interchangeable electric head - without removing the flow switch Degree of protection IP00 Our code 00.0001.0644.1 |
Discover the superior quality and performance of the Valco FCM2-5.15.GO.11P /00.0001.0644.1 with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FCM2-5.15.GO.11P /00.0001.0644.1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FCM2-5.15.GO.11P /00.0001.0644.1 :
At "Parmex Automatización" SRL , we offer the FCM2-5.15.GO.11P /00.0001.0644.1 at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose "Parmex Automatización" SRL ?
Get Your Quote Today! Ready to enhance your operations with the FCM2-5.15.GO.11P /00.0001.0644.1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Valco products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
