BRAND | GSR |
Product | G052.001601.010.009.010 DC24V |
Description | Solenoid valve |
Internal code | PMX4823518 |
Custom code | 84818073 |
Technical specification | GO201167 for connection to 24V DC Reference A52440606T012NT consists of: 052.001601 2/2-way solenoid valve Type: A5244/0606/T012-NT Control type: direct operated, required pressure difference: 0 bar Construction: piston valve Function: NO - opened without current Connection: G1/4 Nominal size: 3.0 mm Pressure: 0 - 10 bar Temperature (medium): -10°C/+130°C Temperature (environment): -10°C/+35°C Viscosity max.: 22 mm²/s Material (housing): stainless steel 1.4305 Material (inner parts): stainless steel 1.4104 Seal: EPDM Installation: drive in an upright or horizontal position Note: NT = NO and high-temperature version up to max. 130°C B0051.000779 with magnetic coil Type: T012 Voltage: 24V DC Dust/water protection: IP65 Power: 18.5 watts Duty cycle: 100% ED Connection type: Device plug according to DIN 43650-A ISO4400 B0040.000047 Device plug 28 x 28 mm, according to DIN 43650, unassembled in a plastic bag Cable screw connection: M20x1.5 connectable cables: Ø4.5-11mm max.1.5mm² Standard: EN 175301-803 Form A/ISO 4400 Voltage: 250V AC or DC Output: max. 1.5A Temperature (environment): -40°C/+90°C .: Housing material PPA6 GF30 .: Seal: NBR (black) - Profile seal GDM 3-16 .: Zinc plated steel screw |
Please Contact Us to Order to offer competitive prices and delivery time for GSR - G052.001601.010.009.010 DC24V Solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Mexico Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
