Buy IGKU 80-60 from Groschopp in Mexico

BRAND	Groschopp
Product	IGKU 80-60
Description	Gear Motor
Internal code	PMX3422028
Weight	5.4
Technical specification	380-440 / 220-254 V, 50 Hz - 380-480 / 220-277 V, 60 Hz - 0.36-0.38 / 0.62-0.66 A. - 1360-1630 U, 85 W, B14, IP65, - Motor wound according to WK 1695101, - Left / right rotation according to circuit diagram S61-0701-30, Motor with phase isolation, Motor UR / UL Conform, Motor with terminal box AK2 and 6-pin terminal board, Circuit diagram in the terminal box, Motor with heat monitor 140 ° C as opener Connections to WAGO terminal, mounted with: . . . . WORM SPUR GEAR Type: Z20 i = 275: 1 n2 = 4.94 rpm, M2 = 62.00 Nm Service factor fB = 0.40 Flange: Ø 110 mm, flange and shaft on the right Gear shaft: Ø 14 mm k6 x 35 mm long with groove + feather key A5x5x20 mm according to DIN 6885 sheet 1 with axial thread M5 according to DIN 332-D Painting according to RAL 5002 - ultramarine blue Lubricant: Centoplex H / 0 Fat filling quantity: 130 + 5 g - Terminal box position: 44 Gearbox mounting position: 1 Execution and dimensions according to Drawing no .: 2012-06-001532

Discover the superior quality and performance of the Groschopp IGKU 80-60 with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The IGKU 80-60 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of IGKU 80-60 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At "Parmex Automatización" SRL , we offer the IGKU 80-60 at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose "Parmex Automatización" SRL ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the IGKU 80-60 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Groschopp products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

IGKU 80-60 B14 - Z 20 mit KLK(AK2)-Lage 44 - GAL 1 - 001532.pdf
