BRAND | Ephy Mess |
Product | PR-SPA-EX-NWT / 901210421000001 |
Description | Temperature Element, Thermocouple |
Internal code | PMX4975394 |
Custom code | 90259000 |
Technical specification | PR-SPA-EX-NWT iBEXu 14 ATEX 1281U IECEx IBE 14.0058U INMETRO TÜV_20.0889 U (II 2G) Ex ia IIC Gb (II 2G) Ex eb IIC Gb Flexible slot thermometer NWT-M-OK-AK-ESH 1Pt100, 3-wire circuit Class A ±0.15°C at 0°C in accordance with DIN EN 60751 PTFE, dimensions: 2.5+0.5/0x7+0.5/0x50±2mm Supply line: shielded hose cable 1x [3xAWG 24/7-Cu-silver-plated/PTFE/PTFE peeling film/Cu-silver-plated/PTFE, Kl=6000mm, diameter: 3.3 mm] WH (RD/RD/WH), Measurement range: -50°C... +180°C Ambient temperature: -50°C... +180°C Dielectric strength: 2.5 kV AC. 50 Hz/1min. Dielectric strength shield against outer jacket: 0.5 kV AC. 50 Hz/1min. Free range: 30mm Shield not placed on the sensor housing Shield removed on the connection side Calibration point (s): 0/70/180 °C Country of origin: Germany AL: N/ECCN: N/HS/Custom Tariff: 90259000 Net weight: 153.95 g/piece The user manual is delivered in German or English. ATTENTION: Please ensure through your ATEX representative that the above article meet your construction requirements if the items only have an ATEX partial certificate (U) and not an ATEX full certificate (X). EPHYMESS is unable to perform this check. |
Discover the superior quality and performance of the Ephy Mess PR-SPA-EX-NWT / 901210421000001 with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PR-SPA-EX-NWT / 901210421000001 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PR-SPA-EX-NWT / 901210421000001 :
At "Parmex Automatización" SRL , we offer the PR-SPA-EX-NWT / 901210421000001 at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose "Parmex Automatización" SRL ?
Get Your Quote Today! Ready to enhance your operations with the PR-SPA-EX-NWT / 901210421000001 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ephy Mess products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
