BRAND | Uwt |
Product | RN 3001A- 013AM3A3A |
Description | Sensor for low level typ RN 3001 - A013AМ3A3A. Technical data - working temperature of the sensor from - 20° С to + 80° С - working pressure - max 10 bar; - power supply: 230 VAC; step of the motor 1 / min; option 24 VDC / 230 VAC; - montage - on flanges DN100 PN16, EN 1092-1 - stainlees steel St. 321; - material - wings - stainlees steel St. 303, body - metal; - length - 100mm - "wing" - Typ B; - explosion proof - no. |
Internal code | PMX4737494 |
Technical specification | ype: [A] RN 3001 Certificate: [0] CE / UKCA / TR-CU Process temperature: [1] max. +80°C (176°F) Process overpressure: [3] max. 10 bar (145.04 psi) Power supply: [A] 230 V AC 50-60 Hz 4 VA Process connection: [M] flange DN100 PN16, EN1092-1 Material process connection: [3] stainless steel Length of extension L: [A] 100 mm (3.94") Material of extension L: [3] stainless steel Measuring vane: [A] boot-shaped 40 x 98 mm (1.57 x 3.86") stainless steel, for 1½" socket Local Certificates: [0] without Bearing at tube end: [0] without Extension / flange welded: [0] without |
Discover the superior quality and performance of the Uwt RN 3001A- 013AM3A3A with "Parmex Automatización" SRL in Mexico . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The RN 3001A- 013AM3A3A is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of RN 3001A- 013AM3A3A :
At "Parmex Automatización" SRL , we offer the RN 3001A- 013AM3A3A at competitive prices and with the fastest delivery times across Mexico . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose "Parmex Automatización" SRL ?
Get Your Quote Today! Ready to enhance your operations with the RN 3001A- 013AM3A3A ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Uwt products, "Parmex Automatización" SRL is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
